Description
| ELECTRICAL | |
| Voltage | 600V confirming to EN/IEC 60947-5-1 |
| Operational current | 1.2 A 600 V AC-15 A600 EN/IEC 60947-5-1
0.27 A 250 V DC-13 Q600 EN/IEC 60947-5-1 |
| Durability | 1000000 cycles, AC-15, 2 A at 230 V, operating rate: 3600 cycle/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C |
| Reliability | Λ < 10exp(-6) at 5 V, 1 mA in clean environment conforming to EN/IEC 60947-5-4 |
| Voltage | |
| Position | 3 position +/- 45o |
| Short circuit protection | 10 A Cartridge fuse type gG confirming to EN/IEC 60947-5-1 |
| mechanical | |
| Mounting Diameter | 22mm |
| Dimension | H42 X W30 X D70 mm |
| Weight | 52g |
| Mechanical durability | 1000000 Cycles |
| material | |
| Bezel material | Plastic |
| Contacts material | Silver alloy (Ag/Ni) |
| Screw head | Cross head compactible with Philips no.1 screwdriver |
| envorinmental | |
| Protection | TH |
| Flammability | UL 94 HB |
| Standard compliance | EN/IEC 60947-1, EN/IEC 60947-5-1,
JIS C 4520 UL 508 CSA C22.2 No.14 |
| Protection class | IP 69, IP 67 (Conforming to IEC 60529), IP 69K |
| Certification | BV CSA LROS DNA GL UL |
| Temperature range | -40 °C to +70 ° |
